HB-THERM

HB-THERM

HB-Therm – Temperiergerät  Typ: HB-180Z3
(Thermo-5)

Wärmeträger Wasser, max. Temperatur 180 °C

Ausführung
Heizung 32 kW
4M Pumpe 50 L/min, 70 m
A2 Kühlung  30 kW , 60 K
Anschlusswert 33 kW, 49 A
Spannung 400 V (380-415 V), 50 Hz; 3LPE

Zusatzausrüstung
ZD Schnittstelle DIGITAL
ZU Pumpenverschleiss-Überwachung
ZB Anschluss für Alarm und Externsteuerung
ZI Schnittstelle HB-Therm internal
ZK Tastaturschutz
ZC Schnittstelle CAN

--------------------------------------------------

HB-Therm – Temperature Control Unit  Type: HB-180Z3
(Thermo-5)

Heat transfer medium water, max. Temperature 180 °C

Execution
Heating 32 kW
4M Pump 50 L/min, 70 m
A2 Cooling  30 kW , 60 K
Connection load 33 kW, 49 A
Voltage 400 V (380-415 V), 50 Hz; 3LPE

Additional equipment
ZD Interface DIGITAL
ZU Pump status monitor
ZB Connection for alarm and external control
ZI Interface HB-Therm internal
ZK Keyboard-protection
ZC Interface CAN



This email address is being protected from spambots. You need JavaScript enabled to view it.


HB-Therm – Temperiergerät  Typ: HB-200T2
(Thermo-5)

Wärmeträger Öl, max. Temperatur 200 °C

Ausführung
Heizung 8,0 kW
FU Pumpe 60 L/min, 60 m
A3 Kühlung  34 kW , 120 K
Anschlusswert 9,1 kW, 14 A
Spannung 400 V (380-420 V), 50 Hz; 3LPE

Zusatzausrüstung
ZD Schnittstelle DIGITAL
ZE Anschluss für Externfühler
ZK Tastaturschutz
ZB Anschluss für Alarm und Externsteuerung

----------------------------------------------------------


HB-Therm – Temperature Control Unit  Type HB-200T2
(Thermo-5)

Heat transfer medium oil, max. Temperature 200 °C

Execution
Heating 8,0 kW
FU Pump 60 L/min, 60 m
A3 Cooling  34 kW , 120 K
Connection load 9,1 kW, 14 A
Voltage 400 V (380-420 V), 50 Hz; 3LPE

Additional equipment
ZD Interface DIGITAL
ZE Connection for external sensor
ZK Keyboard-protection
ZB Connection for alarm and external control

This email address is being protected from spambots. You need JavaScript enabled to view it.


HB-Therm – Temperiergerät  Typ: HB-140U2
(Series-4)

Wärmeträger Wasser, max. Temperatur 140 °C

Ausführung
Heizung 16 kW
DA Pumpe 30 L/min, 52 m
A2 Kühlung  30 kW , 60 K
Anschlusswert 17 kW, 25 A
Spannung 400 V (380-420 V), 50 Hz; 3PE

Zusatzausrüstung
ZL Leckstopbetrieb
ZE Anschluss für Externfühler
ZD Schnittstelle DIGITAL

--------------------------------------------------

HB-Therm – Temperature Control Unit  Type: HB-140U2
(Series-4)

Heat transfer medium water, max. Temperature 140 °C

Execution
Heating 16 kW
DA pump 30 L/min, 52 m
A2 Cooling  30 kW , 60 K
Connection load 17 kW, 25 A
Voltage 400 V (380-420 V), 50 Hz; 3PE

Additional equipment
ZL Leak stopper
ZE Connection for external sensor
ZD Interface DIGITAL

This email address is being protected from spambots. You need JavaScript enabled to view it.




HB-Therm – Temperiergerät  Typ: HB-100Z1
(Series-5)

Wärmeträger Wasser, max. Temperatur 100 °C

Ausführung
Heizung 8 kW
4M Pumpe 50 L/min, 70 m
A2 Kühlung  30 kW , 60 K
Spannung 400 V (380-415 V), 50 Hz; 3LPE

Zusatzausrüstung
ZL Leckstopbetrieb
ZD Schnittstelle DIGITAL
ZI Schnittstelle HB-Therm internal
--------------------------------------------------

HB-Therm – Temperature Control Unit  Type: HB-100Z1
(Series-5)

Heat transfer medium water, max. Temperature 100 °C

Execution
Heating 8 kW
4M pump 50 L/min, 70 m
A2 Cooling  30 kW , 60 K
Connection load 17 kW, 25 A
Voltage 400 V (380-415 V), 50 Hz; 3LPE

Additional equipment
ZL Leak stopper
ZD Interface DIGITAL
ZI Interface HB-Therm internal

This email address is being protected from spambots. You need JavaScript enabled to view it.
